E80XNL Hyster

  Back to Inventory
  • Best in class ergonomics
  • Improved energy efficiency
  • Operator comfort
  • Models: E80XNL
  • Capacity: 8000lbs
  • Load Weight: 8000lbs
  • Max Lift Height: 120
  • Environment: Indoor
  • Power: Electric
  • Primary Task: Lifting and Stacking
  • Auto Manufacturing
  • Beverage
Details
LITHIUM-ION POWER FOR HEAVTY-DUTY APPLICATIONS

The E80XNL provides best in class ergonomics, improved energy efficiency, zero emissions (including no off-gassing during charging process), and low noise operation, making it the ideal solution for customers looking to convert IC trucks to electrics.

Equipment Type
4 Wheel Electric Forklift Trucks

The E80XNL has been specifically designed to take advantage of the form factor of the lithium-ion battery pack, creating greater space in the operator compartment and lowering the center of gravity. Lithium-ion power is an ideal solution for heavy-duty applications due to zero battery maintenance, fast charging, and a long battery life.

  • Air-ride vinyl and cloth seat options allow for a smoother ride, improving operator comfort.
  • Spacious operator compartment allows for more freedom to position feet during operation.

  • Multiple battery sizes allowing to tailor fit application needs
    • 52.4 kWh (83.2V @ 630 Ah)
    • 43.7 kWh (83.2V @ 525 Ah)
    • 34.9 kWh (83.2V @ 420AH)
  • Fast charging speeds available
    • 34.9kW battery can be fully charged in as little as approximately 1 hour and 15 minutes with 30kW charger
    • 52.4kW battery can be fully charged in as little as approximately 1 hour and 45 minutes with 30kW charger
  • For applications with high ambient temperatures and/or high charging demands, cooling options are available. Vented paneling and fans pull air across the battery. Fans will run when:
    • Battery enters thermal cutback
    • Anytime battery is on charge

  • Although longer than the standard battery box E80XN, for ICE replacement, E80XNL is:
    • ~3.2” shorter than an S80FT truck
    • Improves Outside Turning Radius (OTR) by ~2.3” when comparted to an S80FT truck
    • Improves Right Angle Stack by ~2.1” when compared to an S80FT truck
